Easy Operation Single Phase Submersible Pump Control Panel CE Certification
| Product Details: Place of Origin:CHINA Brand Name:Leading orneutral Certification:CE / ISO Model Number:MP-S1 plus Payment & Shipping Terms: Minimum Order Quantity:10 PackagingDetails:carton Payment Terms:L/C, T/T, Western Union,Paypal Supply Ability:2000pcs per month |
Detailed Product Description
Working Temperature: | -25℃-- +55℃ | Working Humidity: | 20%--90%RH, No Drips Concreted |
Degree Of Protection: | IP54 | Install Position: | Wall Mounting |
Shipping Carton Dimension: | 34*36*53cm | Unit Dimension (L X W X H): | 170*155*85mm |
Description:
Easy Operation Single Phase Pump Control Panel (MP-S1 plus)For Submersible Pump With CE Certification
MP-S1 plus,it's an Single Pump Control Panel.If don't connect the level probe,it's same as an motor protector/Starter.It has More control functions,but motor protector just start & protect pump.
Specifications:
Model | MP-S1 plus |
Description | Single Pump Control Panel |
Input Voltage | AC220-240V,Single Phase,50HZ/60HZ,DOL |
Output Power | 0.37-2.2KW(0.5-3HP) |
Capacitor | Reserved space for installing start capacitor |
Degree of protection | IP54 |
Protection Function | Over load protection |
| Over/Under voltage protection | |
| Pump stalled protection | |
| Dry run protection with sensor free | |
Other features | Memory function when power off & recovery |
| LCD screen displaying motor running stats | |
| Push button calibration | |
Main installation data | Working temperature:-25ºC-- +55ºC |
| Working humidity:20%--90%RH, no drips concreted | |
| Install position:Wall mounting | |
Unit dimension(L*W*H) | 170*155*85mm |
Applications:
Control and protect universal pump
Using liquid probe sensor or float switch or pressure switch to control pump start and stop.
Applied for water supply by liquid level control through float switch or liquid probe.
Applied for water supply by pressure control through pressure switch and pressure tank.
Applied for drainage by liquid level control through float switch or liquid probe.
Feature Advantage:
Leading Intelligent Pump Controller Protection function:Under voltage protection and over voltage protection
1.What is pump under voltage and over voltage ?
All electrical equipment has a rated voltage, but it is not guaranteed to work under rated voltage in practice.It is close to the rated voltage range,and the general requirement is ±15%.To protect electrical equipment and process quality, if the voltage is below -15%, it is "under voltage".When the working voltage drops under the voltage,it will take protect action and cut off the power.On the contrary, if the voltage exceeds 15%, the voltage is "over voltage". They are non-fatal failures for electrical equipments.
2. What are the consequences of under voltage and over voltage ?
The insulation of the motor is mainly realized by insulating materials, and the insulation size is limited by geometric space.When the motor is exceed the insulation strength and voltage value of the electrical appliance,It is easy to cause insulation breakdown.The electrical appliances can be hot, punctured, burned and caught fire, even cause an accident.When the voltage is too low,the output torque of the motor is reduced by a square multiple.It is possible to cause motor stalling and overheats,even burns.So the operating voltage range of the motor is very narrow,the over voltage and under voltage protection must be installed.
3.How is Leading’s controller protect the pump when it is in the Under voltage protection and over voltage protection state?
In Leading’s controller, When the real running voltage is lower or higher than the calibrated voltage,pump is in under/over voltage protection state.In this case,the controller will attempt to restart the pump every 5 minutes(Settable time) until line voltage is restored to normal.
4.Other Products And Pictures:
1.Motor protector/motor starter
2.Single pump control panel(universal/ pressure boosting/sewage / drainage pump)
3.Duplex pump control panel(universal/ pressure boosting/sewage / drainage pump)
4.Reverse osmosis control panel
5.Super programmable logic controller
6.Accessories
7.Wifi+app control---coming soon
8.ODM/OEM pump controller
5.FAQ
Q1.Can I get some samples?
A1:Yes, Sample order is available for quality check and market test.
Q2.What's delivery time?
A2:It usually takes about 3-5 working days for small order and 10-15 days for big order.
Q3.What's your payment terms?
A3:We usually accept all kinds of payment terms .Such as T/T,L/C, Western Union.PayPal,Cash.
Q4.What's your warranty terms?
A4:We offer 16 months warranty time.
Q5.Do you have the products in stock?
A5:Depends on your request, We have standard models in stock. Some special products and big order will be newly produced according to your order quantity.
Q6.How does your factory do the quality control?
A6:Quality is priority, we always attach the importance to quality control from the beginning to the end of the production. every product will be fully assembled and carefully tested before packing and shipping.
